1769-AENTR

| 1769-AENTR | CompactLogix communication module


  • Part Number:

    1769-AENTR
  • Weight:

    0.3kg
  • Dimensions:

    18*13*10.5cm
  • Manufacture Year:

    2021
  • Place of Origin:

    USA
  • Certification:

    CO,CQ
  • Description:

    1769-AENTR CompactLogix communication module

Description:

The 1769-AENTR EtherNet/IP distributed I/O system with capabilities

to help you reduce I/O spares. This adapter allows CompactLogix™

customers to reuse their 1769 I/O when migrating to next generation

CompactLogix controller, while keeping the investment of 1769 I/O.

By using the 1769-AENTR you can use the same I/O to standardize

on a single, scalable platform.


Technical Description of 1769-AENTR

TCP/IP Connections 96

Product Type CompactLogix Ethernet IP Adapter

Manufacturer Automation /

Communication ports: Two (2) Ethernet I/P

Topologies: Star, Linear, Device Level Ring (DLR)

Logical Connections: 128 connections

Hardware IP address configuration: Rotary switches

Mounting: DIN Rail

Current draw @ 5V DC: 500 mA


Manager Steve quotes to you

 cn@mooreplc.com            +8618005028963


  +86-18005028963             +86-18005028963

1)Fast delivery:
2)Various payment:
3)Long warranty:  we offer original new with 1 year warrenty


4)Large inventory: Our warehouse is capable of holding up to 60,000 pallet spare parts.
