Part Number:
531X207LCSAMG1Weight:
0.98kgDimensions:
15.2cmX11.8cmX6cmManufacture Year:
2021Place of Origin:
USACertification:
CO,CQDescription:
General Electric/GE Fanuc 531X207LCSAMG1 LAN Current Source Board
Manufacturer: |
General Electric |
Part Number: |
531X207LCSAMG1 |
Description: |
General Electric 531X207LCSAMG1 |
Full Description: |
General Electric 531X207LCSAMG1 LAN Current Source Board
|
Status: |
In stock |
Warranty | 12 Months |
The 531X207LCSAMG1 board was developed as a local area network (LAN) current source board. The
manufacturer, General Electric, designed this card for the 531X replacement series of drive boards. As it
is a standard component of the drive cabinet, this card can be installed into a number of machines across
GE’s brand of drives and exciters. This current source board provides rated power supplies of 5 VDC as well
as 15 VDC to the LAN board when installed. A fuse protected 115 VAC input power source provides necessary
electricity to the board.
Power supplies required by the LAN communication board is provided by this card. A jumper (J1) found on the
board allows users to select between the two provided power supplies. Should these levels be adjusted, users
must then adjust the output accordingly. A potentiometer found on the card allows for the output configuration
. 531X207LCSAMG1 also features a protected fuse as well as a 12-point terminal board. The terminal board
relays all signals sent to and from the card.
