Part Number:
IC694MDL655Weight:
0.24 kgDimensions:
3.5x13.2x13.5cmManufacture Year:
2021Place of Origin:
USACertification:
CO,CQDescription:
General Electric/GE Fanuc IC694MDL646 RX3i 24VDC Positive/Negative Logic 16 Point Input module
|
Manufacturer: |
General Electric |
|
Part Number: |
IC694MDL655 |
|
Series: |
RX3i |
|
Full Description: |
General Electric IC694MDL655 Positive/Negative Logic, Input module
|
|
Status: |
In stock |
| Warranty | 12 Months |
Technical Description of IC694MDL646
The 24VDC Positive/Negative Logic Input module, IC694MDL655,
provides 32 discrete input points. The inputs are positive or negative
logic inputs and will operate at levels up to 30V.
The inputs are arranged in four isolated groups of eight; each group
has its own common. Isolation is provided between the four groups
of inputs, however each group of eight inputs is referenced to the
same user common connection. This module reports no special fault
or alarm diagnostics.
Power to operate field devices can come from an external supply or
from the module’s isolated +24 VDC output.
Green LEDs indicate the ON/OFF status of each point. The blue
band on the front shows that MDL655 is a low-voltage module.
This module can be installed in any I/O slot in the RX3i system.
