Part Number:
PXI-2520Weight:
5.1kgDimensions:
42cm*50cm*18.5cmManufacture Year:
2021Place of Origin:
USACertification:
CO,CQDescription:
NI PXI-2520 80-Channel SPST Relay Module
Description:
The National Instruments PXI-2520 is a general-purpose switch module that features independent single-pole
single-throw (SPST) Form A armature relays. Each relay is nonlatching with very low on-resistance and low
thermal offsets. The PXI-2520 is fully software programmable, and it supports onboard relay count tracking.
With an efficient coupling of voltage/current capability and relay density, this switch module is ideal for automated
test equipment (ATE) loads or for controlling heaters, lights, and fans.
Features:
Relay Connection: SPST (Open)
Number of Relays: 80
Max Switching Voltage: 150 VDC
Max Switch Current: 2 A
Switch Bandwidth: 35 MHz
Scan Rate: 145 cycles/s
