Part Number:
VT3006S35 R1Weight:
0.5 kgDimensions:
3.8 cm x 12.7 cm x 17.8 cmManufacture Year:
2022Place of Origin:
USACertification:
CO,CQDescription:
ANALOG AMPLIFIER CARD
Product Description:
The inlet section can be confi gured for either a fi xed displacement pump or load-sense variable displacement pump. When simultaneous machine functions are actuated, the pre-compensators will automatically adjust to the highest load pressure via a shuttle arrangement, making the system circuit independent of variations in loads and pump pressures. - EDG-DO with Cross Piloted Counterbalance (B1) incorporates one or two Cross Piloted Counterbalance valves which allow free fl ow toward the A and B outlet ports, and lock in a leak free mode the fl ow returning from the actuator. Pilot pressure in the opposite line reduces the pressure setting of the counterbalance valve in proportion to the pilot ratio (4:1) until opening and allowing the fl ow return from the actuator. The pressure setting should be at least 1,3 times the highest expected load. Depending on the version selected, the counterbalance function can be double-acting or singleacting (only A ,only B or both A and B ports).
Manager John quotes to you
sales3@askplc.com
+86 18150117685
+86 18150117685
+86 18150117685
we offer original new with 1 year warrenty
4)Large inventory: Our warehouse is capable of holding up to 60,000 pallet spare parts.
|
