Part Number:
750-306Weight:
0.2 kgDimensions:
5.2 cm x 10.2 cm x 7.0 cmManufacture Year:
2022Place of Origin:
USACertification:
CO,CQDescription:
Fieldbus Coupler DeviceNet Module
Overview:
Communication CANopen
Number of fieldbus nodes on the master max. 110
Baud rate 10 kBd … 1 MBd
Fieldbus segment length max. 1000 m
Transmission medium Shielded Cu cable 3 x 0.25 mm²
Number of modules per node max. 64
Other CANopen features NMT slave
Minimum boot-up
Variable PDO mapping
Emergency message
Life guarding
Configuration of virtual modules
No. of PDOs 32 Tx / 32 Rx
No. of SDOs 2 server SDOs
COB ID distribution SDO, standard
Node ID distribution DIP switches
Communication profile DS-301 V4.1
